Frequency Range:0.1 µHz to 120 MHz
Waveform Types:Sine, Square, Triangle, Ramp, Pulse, Noise, Arbitrary
Resolution:14-bit vertical resolution
Output Amplitude:20 mVpp to 10 Vpp
Phase Shift:+/- 180 degrees
Bandwidth:Up to 120 MHz (-3 dB)
Memory Depth:16 kpts
Trigger Source:Internal, External, Network
Interface:USB, Ethernet, GPIB
The Tektronix 5B40 Arbitrary Waveform Generator is designed to deliver precise and versatile signal generation for demanding applications.
With its wide frequency range and high-resolution waveform types, this generator is perfect for creating complex waveforms for testing and validation.
It offers up to 100 MSa/s sampling rate and +/-10Vpp output amplitude, ensuring reliable performance across a variety of test scenarios.
The device supports multiple waveform types, including sine, square, triangle, ramp, noise, and arbitrary, providing flexibility for diverse testing needs.
The compact design and intuitive user interface make it easy to operate, while its robust construction ensures long-term reliability.
Whether you’re working in the telecommunications industry or developing new automotive electronics, the Tektronix 5B40 offers the precision and versatility needed for modern testing requirements.
