ABB 5SHY5055L0002 | 3BHB026114R0001 | IGCT Module

Material Composition:High-grade aluminum alloy with enhanced thermal conductivity

Maximum Current Rating:5,000 Amperes at 50 Hz

Operating Voltage Range:DC 1500V to 3000V

Insulation Class:Class H

Cooling System:Water-cooled with integrated heat exchanger

Dimensions (WxHxD):200mm x 300mm x 50mm

Weight:5kg

Certifications:CE, UL, IEC

Operating Temperature Range:-40°C to +70°C

    The ABB 5SHY5055L0002 3BHB026114R0001 IGCT Module is engineered for critical power management tasks, ensuring optimal performance in demanding environments. Its robust design and advanced cooling system enable it to handle high currents and voltages with ease, making it suitable for large-scale industrial applications.

    Crafted from high-grade aluminum alloy, this module boasts exceptional thermal conductivity, reducing the risk of overheating during prolonged use. This material choice also ensures a lightweight yet durable construction, enhancing its portability and installation flexibility.

    With a maximum current rating of 5,000 Amperes at 50 Hz, the IGCT Module can seamlessly manage heavy loads without compromising on efficiency. It operates within a wide voltage range, accommodating diverse power systems and providing unmatched adaptability.

    Equipped with an integrated heat exchanger, the water-cooling system ensures consistent temperature control, crucial for maintaining peak performance even under high-stress conditions. This feature significantly extends the lifespan of the module, contributing to lower maintenance costs and operational reliability.

    Engineered with precision, the IGCT Module offers seamless integration into existing power systems, simplifying the upgrade process for customers. It adheres to stringent safety standards, including CE, UL, and IEC certifications, ensuring compliance and peace of mind.

    Designed for operation across a broad temperature range from -40°C to +70°C, this module is ideal for global deployment, supporting a wide array of geographical and climatic conditions. Whether in cold or hot environments, the ABB IGCT Module ensures reliable power distribution and control.
