Operating Voltage:Up to 1500V DC
Current Handling:50A peak
Board Dimensions:170mm x 120mm
Material:Ruggedized FR-4 with embedded copper traces
Temperature Range:-40°C to +150°C
Communication Interface:RS-485 serial communication
Protection Features:Overvoltage and undervoltage protection, short-circuit protection
The EPCOS 1336-BDB-SP6A PCB Gate Drive Board Kit is meticulously designed for applications requiring robust control of high-voltage semiconductor devices. It seamlessly integrates advanced features such as precise gate drive capabilities, ensuring superior performance under various operational conditions.
Crafted from ruggedized FR-4 material with embedded copper traces, this board offers unparalleled durability and electrical integrity, making it ideal for harsh industrial environments. Its ability to handle peak currents up to 50A guarantees reliable operation even in demanding scenarios.
With an operating voltage of up to 1500V DC and a temperature range from -40°C to +150°C, the 1336-BDB-SP6A is versatile enough to withstand extreme environmental conditions without compromising performance. The inclusion of RS-485 serial communication ensures seamless integration with existing systems, facilitating easy setup and configuration.
Safety is paramount in industrial control systems, and the 1336-BDB-SP6A does not disappoint. It comes equipped with overvoltage and undervoltage protection, as well as short-circuit protection mechanisms, safeguarding against potential failures and downtime. These protective measures are essential for maintaining system integrity and operator safety.
Designed with the end-user in mind, the EPCOS PCB Gate Drive Board Kit simplifies the process of managing high-voltage semiconductor devices. Its compact size, efficient power management, and comprehensive feature set make it a valuable asset in a wide range of industrial control applications, from power electronics to motor control systems.
